30 Kg Crop Spraying Uav RC Agricultural Pesticide Drone Sprayer Battery Type Uav Agriculture for Ecuador
- OEM & ODM Service -
Large capacity, large size, great success
- OEM & ODM Service -
Large capacity, large size, great success
The capacity is increased to 30kg and the flight time reaches 25 minutes in no-load mode.In payload mode, it travels at 10 meters per second.Spray at a rate of 10L/min.
The control system adopts agricultural professional controller, the specialized system provides excellent performance support.Can be selected with fertilizer kit, a machine multi-purpose, reduce the cost of use.
The performance of the whole machine is optimized, and the hidden circuit is designed to prolong the service life of components and reduce after-sales problems.
BROUAV adopts industrial grade hardware structure and sensors, available for more communication modes.
The control system adopts agricultural professional controller, the specialized system provides excellent performance support.Can be selected with fertilizer kit, a machine multi-purpose, reduce the cost of use.
The performance of the whole machine is optimized, and the hidden circuit is designed to prolong the service life of components and reduce after-sales problems.
BROUAV adopts industrial grade hardware structure and sensors, available for more communication modes.
| Model | D30L-8 |
| Product Material | Aviation carbon fiber & aviation aluminum |
| Airframe Dimensions(Incl. propellers) | 3090mm*3090mm*830mm |
| Airframe Dimensions(folded) | 890mm*750mm*1680mm |
| Transport Dimensions | 1800*1000*900mm |
| Max Takeoff Weight | 66KG |
| Aircraft Weight | 26KG |
| Maximum Capacity(spraying system) | 30L |
| Flight Altitude | ≤20m |
| Flight Time (Unloaded) | 15~25 minutes |
| Flight Time (Full Loaded) | 5~13 minutes |
| Flight Speed | ≤15m/s |
| Spray Width | 6-12m |
| Spray Flow | 3-10L/min (5L double water pump) |
| Nozzle Type | Imported high pressure anti-floating atomizing nozzle |
| Droplet Size | 60~90μm |
| Flight Controller | Professional industrial version flight controller |
| Navigation Method | GPS/GNSS RTK |
| Operating Efficiency | ≥12 (ha/hr) |
| Safe Takeoff and Landing Wind Speed | ≤8 m/s |
| Motor speed | 5000rpm |
| Battery Voltage | 50.4V |
| Battery Capacity | 16000mAh*2( 12S Intelligent Lithum Battery) |
| Battery Lifespan(Cycle) | ≥500 |
| Intelligent Charger | AC Input 100-240V |
